Características:

• Support video color format: 24bit/deep color 30bit,36bit
• Support audio format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
• Maxbandwidth: 250MHz
• Max baud rate: 7.5Gbps
• Input/Output TMDS signal: 0.5~1.5Volts p-p(TTL)
• Input/Output DDC signal: 5Volts p-p (TTL)
• Input cable distance: ≤15m AWG26 HDMI 1.3 standard cable
• Output cable distance: ≤25m AWG26 HDMI 1.3 standard cable
• Max working current: 650mA
• Power adapter format Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
• Operating Temperature range: (-15 to +55℃)
• Operating Humidity range: 5 to 90%RH (No Condensation)
• Dimension (L x W x H): 115x61x25 (mm)
• Weight: 190g
